Промышленное оборудование · Delta-Mobrey Vertical Control Magnetic Level

XC12FL4N3D4/212-SPE | Delta-Mobrey Vertical Control Magnetic Level Switch

Артикул: QT-94993
от 4 915 296 ₸
В наличии: 0

Предложения складов

СкладЦенаВ тенгеОстатокДоставка

Характеристики

ConditionNew & Original in Factory Packing
Factory Warranty12 Months
ID каталога105013
ModelVertical Control Magnetic Level SwitchBrand: Delta-Mobrey
Part NumberXC12FL4N3D4/212-SPE
Shipping Weight50 Kg
АртикулXC12FL4N3D4/212-SPE

Описание

Vertical Chamber Mount Controlbased on a XC12FL4N3D4/212-SPE with 4-in 300lb ANSI RF top flange seal welded to union. 1-in 300lb ANSI RF process connections on 575mm. 1-in NPT drain. Carbon steel ASTM A105/A106 Gr B. Bolting ASTM A194 2H/A193 B7. Switch points from topprocess connection : HWL = 167mm, LWL = 287mm, LLWL = 332mm. Maximum working pressure 38 bar at 20 deg C.
