TMT72-AAA1AH2A1+B1C1F1G1PB | E+H iTEMP TMT72 Temperature Transmitter

Ordering Information Model TMT72 iTEMP TMT72 Temperature Transmitter Approval AA Non-hazardous area Communication; Output Signal A HART; 4-20mA; HART configuration Housing Shape 1 Form B head transmitter, DIN EN 50446 Electrical Connection A Screw terminals Field Housing H2 TA30H, Alu, 2x M20x1.5, glass display window (w/o display unit), explosion-proof enclosure Device ModelA1 1 Universal Input B1 RTD/Ohm 2-wire Sensor Type C1 Pt100, IEC60751 (a=0.00385), -200...+850oC, min. span 10K Calibration F1 Factory calibration certificate 6-points, fixed Display; Operation G1 Measured value display; DIP-switch, pluggable (TID10) Accessory Enclosed PB Pipe mounting bracket, 316L, diameter 1-2"
