T5-90-10-45-HT-TI-1-0-0-3-0 | Panametrics T5 Flare Gas Transducer

Ordering Information Model T5 T5 All welded gas transducer, Certifications include: ATEX Flameproof II 2 GD Ex d IIC T(x); CSA/C-US Class 1, Div. 1, Groups C, D; IECEx Flameproof Ex d IIC T(x) Head Angle 90 90 deg head angle Frequency 10 100 KHz frequency Tube Length 45 45 inch Tube Length Temperature Range HT High Temperature Range: -50 to 250 deg C (-58 to 482 deg F) Material TI Standard titanium head with titanium tube. Material certs per EN10204 Type 3.1 The transducer material also meets the requirements of NACE MR-01-75 and MR-01-03 Junction Box 1 Explosion proof Aluminum Enclosure XAMP 0 no XAMP (Field Replacement Only) Preamp Gain 0 Gain of Zero - No Preamplifier Required Certification 3 IECEx Ex d IIC T6...TX Gb Hazardous Locations Miscellaneous 0 None
