T5-18-10-33-NT-TI-2-0-0-1-0 | Panametrics T5 Flare Gas Transducer

T5/T5 MAX Transducer Physical Specifications: Applications Hazardous Area, Flare Gas, Hydrocarbon Gases, Saturated Steam Installation Type WettedStandard: Titanium Material Optional: 316 Stainless Steel, Monel® or Hastelloy® Field Mounting Flowcell, Hot or Cold Tap Process Connection Flanged, 1.5 in. to 3 in. (40 mm to 80 mm) Holder Type Insertion Mechanism Holder Ratings 150#, 300#, 600#Standard: 100 kHz Operating Frequency Optional: 50 kHz and 200 kHz Pressure Range 0 to 2700 psig Standard,0 to 1500 psig for USA/Canada Certified Products Electrical Rating 200 V peak-to-peak, 5 mA Ambient Temperature Range –40° to +140°F (–40° to +60°C) Process Temperature Range –364° to +572°F (–220° to +300°C)-55ºC to 150ºC for T5 Max Only
