Ordering Information Model STR74G STR700 SmartLine Remote Diaphragm Seals Number of Seals 1 1 Remote Seal (High Side) Primary Fill Fluid (Meter body) 1 Silicone Oil 200 Construction: In-Line Gauge A Non-Wetted Adapter Head Materials: 316 SS Bonnet Bolts and Nuts for Transmitter Heads 0 None Secondary Fill Fluid (capillary & seal)** 1 Silicone Oil 200 Connection of Remote Seal to Meter Body** D Capillary Length: 20 feet (6.1 m), SS Armor Seal Option** 0 None Flush Flanged Seal** DDC Wetted Material BA Diaphragm: 316L SSUpper Insert: 316L SS Non-Wetted Material (upper, upper insert) 4 Upper: 316L SSUpper Insert: 316L SS Bolts(1) 0 No Selection Flushing Connection and Plugs(2) 0 316L SS Gasket G Grafoil® Approvals C ATEX Explosion proof, Intrinsically Safe & Non-incendive Electronic Housing Material & Connection Type B Material: Polyester Powder Coated AluminumConnection: M20Lightning Protection: None Output/ Protocol H Analog Output: 4-20mA dcDigital Protocol: HART Protocol Customer Interface Selections C Indicator: BasicExt Zero, Span & Config Buttons: YesLanguages: English Application Software 1 Standard Diagnostics Output Limit, Failsafe & Write Protect Settings 3 Write Protect: EnabledFail Mode: High> 21.0mAdcHigh & Low Output Limits(3): Honeywell Std (3.8 - 20.8 mAdc) General Configuration C Custom Configuration (Unit Data Required from customer) Accuracy and Calibration B Accuracy: StandardCalibrated Range: Custom (Unit Data Required)Calibration Qty: Single Calibration Mounting Bracket 7 Bracket Type: Flat BracketMaterial: 316 SS Customer Tag 1 One Wired Stainless Steel Tag (Up to 4 lines 26 char/line) Unassembled Conduit Plugs & Adapters A7 M20 316 SS Certified Conduit Plug Certifications & Warranty TPF1FXF5FG Over-Pressure Leak Test Certificate (1.5X MAWP) (F3392)Calibration Test Report & Certificate of Conformance (F3399)EN10204 Type 3.1 Material Traceability (FC33341)Certificate of Origin (F0195)NACE MR0175; MR0103; ISO15156 (FC33338) Process wetted parts only Factory 0 0 0 0 Factory Identification ** Refer to 34-ST-00-128 for additional options, consult factoryBolt material w ill be same as Upper Material. How ever, if Table I bolts/nuts material is NACE or B7M, seal bolt material w ill be 304 SS NACE.Plastic Plugs are TEMPORARY ONLY to protect threads and MUST be REMOVED before installation NAMUR Output Limits 3.8 - 20.5mAdc can be configured by the customer or select custom configuration Table Vc
