SE4304T01 | DeltaV™ Analog Output 4-20 mA HART

Features:Eliminate marshalling and add I/O anywhere in the plant without affecting control room cabinetsNo marshalling cabinet or cross-wiring, fewer wires, much less work and fewer contact points for potential failures Specifications Sensor Types 4 to 20 mA with or without HART, 0 to 20 mA Nominal Signal Range (span) 4 to 20 mA, (0 to 20 mA option) Full Signal Range 0 to 24 mA Accuracy over temperature range 0.25% of span (0 to 60°C), 0.5% of span (-40 to 70°C) Resolution 16 bit D/A converter Calibration None Required Available Field Power 20 mA at 15 V DC supply into 750 O load Field Circuit Protection 24 mA Current Limiting Circuit, Field wiring disconnect CHARM Power req. 42 mA max @ 24 V DC CHARM Heat Dissipation 0.48 W HART Support HART v7 pass-through for AMS, HART v7 variable and device status available to control HART Data Update Rates Update rates are faster than every second dependent on HART communication loading and device type
