PLX32-EIP-PND | ProSoft Technology EtherNet/IP™ to PROFINET® Gateway

The EtherNet/IP to PROFINET device gateway offers bi-directional data transfers between a PROFINET Controller and EtherNet/IP networks. The PLX32-EIP-PND gateway is a stand-alone DIN-rail mounted unit that provides two Ethernet ports, with each port using a different subnet. The onboard SD Card slot (SD card optional) is used for storing configuration files that can be used for recovery, transferring the configuration to another gateway, or general configuration backup. The EtherNet/IP Driver uses Class 1 I/O connections or Class 3 Message instructions. The PROFINET driver operates as a PROFINET Class A device.Features and Benefits:ODVA ApprovedPROFINET v2 certification with PROFINET Class A complianceEtherNet/IP and PROFINET certifications ensure the device is compatible with their respective networkField-tested with multiple PROFINET controllers from multiple vendorsRemotely view and diagnose EtherNet/IP and PROFINET networksEmbedded EDS AOP provided to allow for seamless integration to Studio 5000 and RSLogix 5000Using EtherNet/IP I/O connections, no ladder programming is requiredMultiple I/O connections to allow for increased throughputSecure module configuration via module switch (v1.04 and greater)Up to 10,000 16-bit registers can be used to exchange large amounts of data
