MVI56-GSC | Prosoft Technology Generic Serial ASCII Interface Module

Part Number: MVI56-GSCModel: Generic Serial ASCII Interface ModuleManufacturer: Prosoft TechnologyFeaturesBenefitsBackward-CompatibleMVI56E products are backward-compatible with existing ladder logic, allowing for a smooth transition when upgrading from the earlier version MVI56-GSC product.RSLogix™ 5000 IntegratedModule communication is integrated within RSLogix 5000 using a sample Add-On Instruction (AOI), or sample ladder logic fileThe module is configured with the sample ladder logic controller tagsGraphical User Interface SoftwareProsoft Configuration Builder provides online diagnostics using the high-speed Ethernet portCIPconnect®-enabled, allows remote diagnostic access across multiple bridged EtherNet/IP™ and ControlNet™ networks using Rockwell Automation 1756-ENxT and 1756-CNB network interface modulesProSoft Discovery ServiceProSoft Discovery Service, a software utility to locate MVI56E modules on the network and assign a temporary IP address for easy configurationSpecificationsBackward-compatible with previous MVI56-GSC versionSingle Slot - 1756 ControlLogix backplane compatible10/100 MB Ethernet port for network configuration and diagnostics with Auto Cable Crossover DetectionUser-definable module data memory mapping of up to 5000 16-bit registersCIPconnect-enabled network diagnostics and monitoring using ControlLogix 1756-ENxT modules and EtherNet/IP pass-thru communicationsSample Ladder Logic or Add-On Instruction (AOI) used for data transfers between module and processor and for module configurationInternal web page providing access to product documentation, module status, and firmware update software4-character, scrolling LED display of status and diagnostic data in plain EnglishProSoft Discovery Service (PDS) software finds the module on the network and assigns a temporary IP address to facilitate module access
