LV431756 | Schneider Electric Circuit Breaker

Part Number: LV431756Model: Circuit breaker Compact NSX250HBrand: Schneider ElectricCharacteristicsRange: CompactProduct name: Compact NSXDevice short name: Compact NSX250HProduct or component type: Circuit breakerDevice application: MotorPoles description: 3PProtected poles description: 3t[In] rated current: 220 A at 65 °C[Ue] rated operational voltage: 690 V AC 50/60 HzNetwork type: ACNetwork frequency: 50/60 HzSuitability for isolation:Yes conforming to EN 60947-2Yes conforming to IEC 60947-2Utilisation category: Category A[Icu] rated ultimate short-circuit breaking capacity:85 kA at 240 V AC 50/60 Hz conforming to UL 50865 kA at 480 V AC 50/60 Hz conforming to UL 50810 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-235 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-265 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-270 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-215 kA at 600 V AC 50/60 Hz conforming to UL 508Performance level: H 70 kA 415 V ACTrip unit name: MATrip unit technology: MagneticTrip unit protection functions: IControl type: ToggleCircuit breaker mounting mode: Fixed
