LV430404 | Schneider Electric Circuit Breaker

CharacteristicsRange: CompactRange of product: NSX100...250Product or component type: Basic frameDevice short name: Compact NSX160HDevice application: DistributionPoles description: 3PProtected poles description: 3t[In] rated current: 160 A at 40 °C[Ui] rated insulation voltage: 800 V AC 50/60 Hz conforming to IEC 60947-2[Uimp] rated impulse withstand voltage: 8 kV conforming to IEC 60947-2[Ue] rated operational voltage: 690 V AC 50/60 Hz conforming to IEC 60947-2Network type: ACBreaking capacity code: HBreaking capacity:10 kA at 600 V AC 50/60 Hz conforming to UL 50885 kA at 240 V AC 50/60 Hz conforming to UL 50865 kA at 480 V AC 50/60 Hz conforming to UL 50810 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-235 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-265 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-270 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2[Ics] rated service breaking capacity:10 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2100 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-235 kA at 525 V AC 50/60 Hz conforming to IEC 60947-250 kA at 500 V AC 50/60 Hz conforming to IEC 60947-265 kA at 440 V AC 50/60 Hz conforming to IEC 60947-270 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2Suitability for isolation:Yes conforming to EN 60947-2Yes conforming to IEC 60947-2Utilisation category: Category APollution degree: 3 conforming to IEC 60947-1
