KL4408 | Beckhoff Bus Terminal
Классический аналоговый выходной терминал, обеспечивающий сигналы от 0 до 10 В с разрешением 12 бит. Использует одноканальную технологию для минимизации пространства.
Запросить ценуПредложения складов
| Склад | Цена | В тенге | Остаток | Доставка |
|---|---|---|---|---|
| склад-3 | По запросу | Цена по запросу | 1 | 30–45 дней |
Характеристики
| Condition | New & Original in Factory Packing |
|---|---|
| Factory Warranty | 12 Months |
| ID каталога | 103379 |
| Manufacturer | Beckhoff |
| Model | Bus Terminal, 8-channel analog output, voltage, 0…10 V, 12 bit, single-ended |
| Part Number | KL4408 |
| Артикул | KL4408 |
Описание
The KL4408 analog output terminal generates signals in the range between 0 to 10 V. The voltage is supplied to the process level with a resolution of 12 bits and is electrically isolated. The KL4408 combines eight channels in one housing and is particularly suitable for space-saving installation in control cabinets. The use of single conductor connection technology enables the connection of multi-channel actuator technology with minimum space requirements.The Bus Terminal has a common ground potential. The power contacts are connected through. The reference ground of the outputs is the 0 V power contact. The LEDs indicate the data exchange with the Bus Coupler.
