Ordering Information Model IDP05S(1) Differential Pressure Transmitter, Value Tier Electronics Versions/Output Signals -T HART and 4 to 20 mA with SIL 2 Structure — Traditional(2) 22 316 ss Cover; 316L ss Diaphragm; Silicone Fill; Max Static Pressure=25 MPa (3626 psi) Span Limits C Electronics: 0.62 and 250 kPa; 2.5 and 1000 inH2O; 6.2 and 2500 mbar Process Connector Type (Same Material as the Process Cover) 0 None Conduit Connection and Housing Material 1 1/2 NPT Conduit Connection, Both Sides, Aluminum Housing Electrical Certifications FP FM multiple certifications (includes FM Codes FA, FD or FN) Refer to Accuracy (Includes Linearity, Hysteresis, and Repeatability), page 34 for accuracy specifications.Maximum static pressure can be derated by optional selections.
