Ordering Information Model IDP05S(1) Differential Pressure Transmitter, Value Tier Electronics Versions/Output Signals -T HART and 4 to 20 mA with SIL 2 Structure — Traditional(2) 22 316 ss Cover; 316L ss Diaphragm; Silicone Fill; Max Static Pressure=25 MPa (3626 psi) Span Limits B Electronics: 0.12 and 50 kPa; 0.5 and 200 inH2O; 1.2 and 500 mbar Process Connector Type (Same Material as the Process Cover) 2 1/2 NPT(3) Conduit Connection and Housing Material 1 1/2 NPT Conduit Connection, Both Sides, Aluminum Housing Electrical Certifications AP ATEX multiple certifications (includes ATEX Codes AA, AD and AN)(4) Optional Mounting Bracket Sets(5)(6) -M1 Standard Style Painted Steel Bracket with Plated Steel Bolts Miscellaneous Optional Selections -V Supply Vent Screw in Side of Each Process Cover(7) Refer to Accuracy (Includes Linearity, Hysteresis, and Repeatability), page 34 for accuracy specifications.Maximum static pressure can be derated by optional selections.Not available with structures that have seals on both sides.Not available with Electronics Version -V.Not available with Structure codes F1, F2, F3, and F4 (direct connect seal).Not available with Low Profile (LP1 and LP2) structures.Available only with Traditional Structure codes.
