IC695ALG600 | GE Fanuc PACSystems RX3i Universal Analog Input Module

Channels can be individually-configured using the Machine Edition software for:Any combination of up to 8 channels of voltage, current, thermocouple, RTD, and resistance inputs.Thermocouple Inputs: B, C, E, J, K, N, R, S, TRTD Inputs: PT 385 / 3916, N 618 / 672, NiFe 518, CU 426Resistance Inputs: 0 to 250 / 500 / 1000 / 2000 / 3000 / 4000 OhmsCurrent: 0–20 mA, 4–20 mA, +20 mAVoltage: +50mV, +150 mV, 0–5 V, 1–5 V, 0–10 V, +10V Module Features:Completely software-configurable, no module jumpers to setSix hardware analog-to-digital filter frequencies, individually-selectable by channelRapid channel acquisition times based on filter frequencyFull autocalibrationOn-board error-checkingOpen-circuit detection for most input typesShort-circuit detection for RTDs.User-defined scalingHigh alarm, low alarm, high-high alarm, low-low alarm detection and reportingModule fault reportingSupports diagnostic point fault contacts in the logic program.Flash memory for future upgradesModule Status, Field Status, and TB LEDsCJC compensation on terminal blockTemperature in Celsius or FahrenheitPositive and negative Rate of Change AlarmsConfigurable software filters for each input channelConfigurable interrupts for channel alarms and faultsTerminal Block insertion or removal detection
