IC694MDL930 | GE Fanuc Isolated Relay Output Module

Product Number: IC694MDL930Model: Isolated Relay Output ModuleManufacturer: GE FanucCondition: New & Original in Factory PackingFactory Warranty: 12 MonthsSpecificationsRated Voltage24 volts DC, 120/240 VAC (nominal - see the following table for exceptions)Operating Voltage5 to 30 volts DC5 to 250 VAC, 50/60 HzOutputs per ModuleEight isolated outputsIsolation: Field to Backplane and to Frame Ground250 VAC continuous; 1500 VAC for 1 minute Point to Point250 VAC continuous; 1500 VAC for 1 minuteMaximum Load4 Amps resistive maximum per output2 Amps pilot duty per output20 Amps maximum per module for UL installationsMaximum Load depends on the ambient temperature as shown belowMinimum Load10mAMaximum Inrush5 AmpsOn Response Time15ms maximum¹Off Response Time15ms maximum¹Power Consumption6mA (all outputs on) from 5 volt bus on backplane70mA (all outputs on) from relay 24V bus on backplaneNote:When this module is used with DC power supply IC695PSD040 or PSD140, special precautions should be taken because dropouts in the source voltage will be seen by this module and may cause relay dropouts.
