IC200ALG264 | GE Fanuc VersaMax Analog Input Module
Артикул: QT-138
от 396 111 ₸
В наличии: 1
Предложения складов
Склад
Цена
В тенге
Остаток
Доставка
склад-3
836,40 USD
396 111 ₸
1
30–45 дней
Характеристики
Condition
New & Original in Factory Packing
Estimated Lead Time
Usually Ships in 1 - 7 Working Days
Factory Warranty
12 Months
ID каталога
131
Manufacturer
GE Fanuc
Model
VersaMax Analog Input Module
Part Number
IC200ALG264
Shipping Weight
2 Kg
Артикул
IC200ALG264
Описание
SpecificationsModel: VersaMax Analog Input Module, 15 Bit Current, 15 ChannelLifecycle Status: ActiveInput Range: 0 to 20 mA or 4 to 20 mANumber of Channels: 15External Power Supply: NoneResolution: 4 to 20 mA: 0.5micro Amp= 1 count; 0 to 20 mA: 0.625micro Amp = 1 countUpdate Rate: 7.5 msAccuracy at 25°C: ±0.3% typical of full scale, ±0.5% maximum of full scaleInput Impedance: Voltage mode: 100 kOhms maximum, Current mode: 200 Ohms maximumInput Filter Response: 24 Hz ±20%5V Backplane Current Consumption (mA): 100 maximum3.3V Backplane Current Consumption (mA): N/ALED Indicators: INT PWR LED indicates internally-generated field power is present. OK LED indicates backplane power is present.Dimensions (W x H x D): 110 mm (4.3 in) x 66.8 mm (2.63 in) x 50 mm (1.956 in) , not including the height of the carrier or the mating connectors
