GLAC01A2B | Honeywell MICRO SWITCH GLA Series Global Limit Switches

OverviewMICRO SWITCH GLA Series Global Limit Switches, Side Rotary With Roller - Adjustable, 1NC 1NO SPDT Snap Action, 20 mm.Honeywell’s MICRO SWITCH GLA Limit Switch Series is designed to global EN50041 standards and well suited for worldwide applications. The modular design (heads/actuators, bodies, and contact blocks) of the limit switch allows for rapid response to meet customer applications. The rugged die-cast metal housing of the switch is ideal for indoor and outdoor applications where a degree of IP or NEMA enclosure sealing is required. Normally closed snap-action contacts and normally closed slow-action contacts are positive opening. Technical Specifications Availability Global Pretravel (PT) 26° Differential Travel (DT) 12° max. Actuator Side Rotary Circuitry 1NC 1NO SPDT Snap Action Housing Material Zinc Die-Cast Sealing IP67; NEMA 1, 4, 12, 13 Lever Type Roller - Adjustable Shock 50 g per IEC 68-2-27c (w/o Actuator) Operating Temperature -25 °C to 85 °C [-13 °F to 185 °F] Operating Force (OF) 0,330 N m [2.90 in lb] Overtravel (OT) 59°
