SpecificationsType: M8 Connector *1Main unit/expansion unit: Main unitNumber of control outputs: 2 *2Number of external inputs: 1 *2LED source LED: Transmitter side: Red, four-element LED (wavelength 660 nm)Response time: 23 µs (S-HSPD *3)/50 µs (HSPD *4) / 250 µs (FINE) / 500 µs (TURBO) / 1 ms (SUPER) / 4 ms (ULTRA) / 16 ms (MEGA) / 64 ms (TERA)Ensure the cable length is 30 m or less for the M8 connector type.Ensure the cable length is 20 meters or less when connecting by way of IO-Link.Output 2 and the external input are selectable.Restrictions when S-HSPD is selectedOutput 2 of dual output types is fixed to OFF.IO-Link communication cannot be used.Area detection, Area % Mode, DATUM, Rising edge, and Falling edge cannot be selected for Detection Mode.Output timer, Limit Detection, and Display Gain cannot be used.FULL cannot be selected for the ECO function.Restrictions when HSPD is selectedDisplay Gain cannot be used.
