DRT2-DA02 | Omron Analog I/O Terminals

General Specifications Model DRT2-DA02 Communications power supply voltage 11 to 25 VDC (Supplied from the communications connector) Current consumption 120 mA max. (24 VDC)220 mA max. (11 VDC) Noise immunity Conforms to IEC61000-4-4, 2 kV (power line) Vibration resistance 10 to 150 Hz, 0.7-mm double amplitude Shock resistance 150 m/s² Dielectric strength 500 VAC for 1 min between the communications circuit and analog circuit (1 mA sensing current) Ambient operating temperature -10°C to 55°C (with no icing or condensation) Ambient operating humidity 25% to 85% Ambient operating atmosphere No corrosive gases Ambient storage temperature -20°C to 65°C Mounting method DIN 35 mm-track mounting Mounting strength 50 N10 N (in the DIN Track direction) Screw tightening torque M3 (power, I/O terminal): 0.5 Nm Weight 150 g max.
