OmronPLC, 100-240 VAC supply, 36 x 24 VDC inputs, 24 x relay outputs 2 A, 10K steps program + 32K words data memoryFeatures"CP1L-EM" and "CP1L-EL" have complete with a Ethernet port.Pulse output for two axes. Advanced power for high-precision positioning control.High-speed Counters. Single-phase for four axes.Six interrupt inputs are built in. Faster processing of instructions speeds up the entire system.Serial Communications. Two ports. Select Option Boards for either RS-232C or RS-485 communic
Model
CPU Unit
Part Number
CP1L-M60DR-A
Shipping Weight
1 Kg
Артикул
CP1L-M60DR-A
Описание
Part Number: CP1L-M60DR-AModel: CPU UnitManufacturer: OmronPLC, 100-240 VAC supply, 36 x 24 VDC inputs, 24 x relay outputs 2 A, 10K steps program + 32K words data memoryFeatures"CP1L-EM" and "CP1L-EL" have complete with a Ethernet port.Pulse output for two axes. Advanced power for high-precision positioning control.High-speed Counters. Single-phase for four axes.Six interrupt inputs are built in. Faster processing of instructions speeds up the entire system.Serial Communications. Two ports. Select Option Boards for either RS-232C or RS-485 communications."CP1L-M" and "CP1L-L" have a peripheral USB port.The Structured Text (ST) Language. Makes math operations even easier.Can be used for the CP1W series Unit. The extendibility of it is preeminently good.LCD displays and settings. Enabled using Option Board.
