C60M40-40-050 | Prosoft Technology LMR 600 Cables

Part Number: C60M40-40-050Model: LMR® 600 CablesManufacturer: Prosoft TechnologyLMR® 600 Type Cables are ideal for antenna feed runs greater than one-hundred feet.Features and BenefitsFlexibleWith a 1 ½ -inch minimum bend radius, LMR® 600 cable can be easily routed into and through tight spaces without kinking.Low LossLMR® 600 has the lowest loss of any ½-inch superflex cable. This is achieved through the use of a high velocity gas-injected closed cell foam dielectric, and bonded aluminum tape outer conductor.WeatherproofThe UV protected black polyethylene jacket makes the cable rugged and resistant to the full range of outdoor environments.RF ShieldingThe bonded aluminum tape outer conductor is overlapped to provide 100% coverage, resulting in >90 dB RF shielding (>180 dB crosstalk) and excellent interference immunity (ingress and egress).Phase StabilityThe intimately bonded structure and foam dielectric of LMR® cables provide excellent phase stability over temperature and with bending. The high velocity dielectric results in superior phase stability as compared with solid and air-spaced dielectric cables.
