ApplicationModule 87TS01 is a coupling module for connecting computers or external systems to the PROCONTROL system.For this purpose, the module is equipped with a serial interface type RS232c or RS422 through which a process operator station POS, a programming, diagnosis and display system PDDS, control diagnosis station CDS or another computer can communicate with the PROCONTROL system.The module’s scope of action extends over the entire PROCONTROL system.The application of the various module versions is described in the relevant application descriptions.FeaturesThe module can be used in any station belonging to the PROCONTROL bus system using a redundant 24 V module supply (starting with 89MS01/S0200 or 89MS02/R0100). It is equipped with a standard interface for the PROCONTROL station bus.This module requires 2 divisions for mounting space. It can be plugged into subrack slots with address wiring 1 through 58 for the station bus.The module uses a standard interface for participating in data communication within the PROCONTROL system.The telegrams received from the station bus are checked for error – free transmission.Using a serial RS 232c interface, the module is capable of receiving instructions and data coming from a computer in accordance with a defined protocol, as well as transferring instructions and data to a computer.
