SITRANS P320 Gauge Pressure Transmitter
Газоаналитический преобразователь давления, измеряющий давление и давление газа. Максимальный диапазон измерения: 16 bar (232 psi). Диаметр трубопровода: 1/2-14 NPT.
Предложения складов
| Склад | Цена | В тенге | Остаток | Доставка |
|---|
Характеристики
| Condition | New & Original in Factory Packing |
|---|---|
| Estimated Lead Time | 10 - 12 Weeks |
| Factory Warranty | 12 Months |
| ID каталога | 101011 |
| Manufacturer | Siemens |
| Model | SITRANS P320 Gauge Pressure Transmitter |
| Part Number | 7MF0300-1QE01-5BF1-Z A00+C11+C12+C14+E20+Y01 |
| Shipping Weight | 8 Kg |
| Артикул | 7MF0300-1QE01-5BF1-Z A00+C11+C12+C14+E20+Y01 |
Описание
SITRANS P320 Pressure transmitter Gauge pressure HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 16 bar (232 psi) Female thread 1/2-14 NPT Diaphragm: Stainless steel 316L/1.4404, measuring cell: Stainless steel 316L/1.4404; Sensor Differential pressure: process flange: Stainless steel 316/1.4408 Die-cast aluminum housing Dual chamber device Intrinsic safety 2 x M20 x 1.5 With display (closed lid) Cable gland and sealing plug attached, plastic Quality inspection certificate - 5 point factory calibration (IEC 60770-2) Inspection certificate (EN 10204-3.1) - material of pressure-containing and wetted parts Factory certificate (EN 10204-2.2) - wetted parts ATEX (Europe) Measuring range setting: Lower range value (max. 5 characters). Upper range value (max. 5 characters). Unit (mbar. bar. kPa. MPa. psi. ...) Example: -0.5 ... 10.5 psi
