SITRANS P320 Pressure transmitter Gauge pressure HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 16 bar (232 psi) Male thread G1/2 (DIN EN 837-1) Process connection: Stainless steel 316L/1.4404, Seal diaphragms: Stainless steel 316L/1.4404, Sensor differential pressure: Process flange: Stainless steel 316/1.4408 (PN160) // 316Ti/1.4571 (PN420) Die-cast aluminum housing Dual chamber device no Ex 2 x M20 x 1.5 Without display (closed lid) General approval without Ex approval: World (CE, UKCA, RCM, CSA, EAC, FM, KC) Measuring range setting: Lower range value (max. 5 characters), Upper range value (max. 5 characters), Unit (mbar, bar, kPa, MPa, psi, ...) Example: -0.5 ... 10.5 psi (stainless steel plate) Location designation (Tag) (stainless steel plate. device parameters. max. 32 characters) TAG plate without marking please order via option D40 Measuring location description (stainless steel plate. device parameters. max. 32 characters)
