7MF0300-1NU01-5AM2-Z C11+E00+Y01
Гauge pressure transmitter, HART (4...20 mA), stainless steel 316L/1.4404, process flange: stainless steel 316/1.4408, dual chamber device, 2 x 1/2-14 NPT
Предложения складов
| Склад | Цена | В тенге | Остаток | Доставка |
|---|
Характеристики
| Condition | New & Original in Factory Packing |
|---|---|
| Estimated Lead Time | 10 - 12 Weeks |
| Factory Warranty | 12 Months |
| ID каталога | 103216 |
| Manufacturer | Siemens |
| Model | SITRANS P320 Gauge Pressure Transmitter |
| Part Number | 7MF0300-1NU01-5AM2-Z C11+E00+Y01 |
| Shipping Weight | 5 Kg |
| Артикул | 7MF0300-1NU01-5AM2-Z C11+E00+Y01 |
Описание
SITRANS P320 Pressure transmitter Gauge pressure HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 63 bar (914 psi) Female thread 1/2-14 NPT Process connection: Stainless steel 316L/1.4404, Seal diaphragms: Stainless steel 316L/1.4404, Sensor differential pressure: Process flange: Stainless steel 316/1.4408 Die-cast aluminum housing Dual chamber device no Ex 2 x 1/2-14 NPT With display (lid with glass window) Cable gland and sealing plug attached, plastic General approval without Ex approval: World (CE, UKCA, RCM) except: CSA, EAC, FM, KC Measuring range setting: Lower range value (max. 5 characters), Upper range value (max. 5 characters), Unit (mbar, bar, kPa, MPa, psi, ...) Example: -0.5 ... 10.5 psi (stainless steel plate)
