Ordering Information Model 7MF030 SITRANS P320 Pressure transmitters for gauge pressure (pressure series) 0 HART, 4 ... 20 mA Measuring cell filling 1 Silicone oil Maximum measuring span J 1000 mbar (14.5 psi) Process connection K Flush-mounted diaphragm Wetted parts materials: Process connection, seal diaphragm 0 Stainless steel 316L/1.4404, stainless steel 316L/1.4404 Non-wetted parts materials 1 Die-cast aluminum Enclosure 5 Dual chamber device Type of protection B Intrinsic safety Electrical connections/cable entries F Thread for cable gland2 x M20 x 1.5 Local operation/display 2 With display (cover with glass pane) -Z Explosion protection approvals E20ATEX (Europe) Flanges according to DIN EN 1092-1 Form B1 and ASME standard B16.5 M30 ASME B16.5• 1" Class 150 RF
