7MF0300-1JF01-5BF1-Z E20 | Siemens SITRANS P320 Gauge Pressure Transmitter

Ordering Information Model 7MF030 SITRANS P320 Pressure transmitters for gauge pressure (pressure series) 0 HART, 4 ... 20 mA Measuring cell filling 1 Silicone oil Maximum measuring span J 1000 mbar (14.5 psi) Process connection F Wetted parts materials: Process connection, seal diaphragm 0 Stainless steel 316L/1.4404, stainless steel 316L/1.4404 Non-wetted parts materials 1 Die-cast aluminum Enclosure 5 Dual chamber device Type of protection B Intrinsic safety Electrical connections/cable entries F Thread for cable gland2 x M20 x 1.5 Local operation/display 1 With display (cover closed) -Z Explosion protection approvals E20ATEX (Europe)
