Features Sensor/ detection principle Photoelectric proximity sensor, Energetic Dimensions (W x H x D) 12 mm x 12 mm x 65.5 mm Housing design (light emission) Cylindrical Housing length 65.5 mm Thread diameter (housing) Round connector M12 x 1 Sensing range max. 0 mm ... 340 mm(1) Sensing range 2 mm ... 300 mm Focus Approx. 5.3° Type of light Infrared light Light source LED(2) Light spot size (distance) Ø 28 mm (300 mm) Angle of dispersion Approx. 5.3° Wave length 880 nm Adjustment Single teach-in button (Sensing range)(3)Selectable via control input C (Sensing range)(4) Object with 90 % reflectance (referred to standard white, DIN 5033). Average service life: 100,000 h at TU = +25 °C. Manual, via teach-in button.Electronically via control input C (0 V).
