4WMM10J31 | Rexroth WMM Directional Control Valve

Part Number: 4WMM10J31Model: WMM Directional Control ValveBrand: RexrothDirectional valves type WMM & WMR are lever operated directional spool valves. They control the start, stop, and direction of a flow. These directional valves basically consist of housing; lever; control spool; return springs. A full array of spools are possible with variations for detented operation on both 2-position or 3-position functions. Flow and pressure rates from 4000 PSI to 5000 PSI and 16 GPM to 32 GPM cover a wide range of applications.Features:Size 6 and 10For mounting:Size 6: Porting pattern according to ISO 4401-3, NFPA T3.5.1M R1, and ANSI B 93.7 D 03Size 10: Porting pattern according to ISO 4401-5, NFPA T3.5.1M R1, and ANSI B93.7 D 05Operation by means of manual lever
