415920 | Yokogawa Shunt Resistor

Артикул: QT-40838
от 73 880 ₸
В наличии: 0

Предложения складов

СкладЦенаВ тенгеОстатокДоставка

Характеристики

Estimated Lead Time8 - 10 Weeks
ID каталога44676
ManufacturerYokogawaModel and Suffix CodesModelDescription415920250 ohm resistance (for 4 mm screws)CharacteristicsResistance Tolerance: ±0.1 %TCR (ppm/°C): ±25 ppm/ºCRated Power: 0.3 WAllowable maximum current: 35 mARecommended input current: 4-20 mARated Ambient Temperature: 70 ºCOperational Temperature Range: -25 to +80 ºCStorage Temperature Range: -40 to +85 ºC
ModelShunt Resistor for Screw Input Terminal
Part Number415920
Shipping Weight1 Kg
Артикул415920

Описание

Part Number: 415920Model: Shunt Resistor for Screw Input TerminalManufacturer: YokogawaModel and Suffix CodesModelDescription415920250 ohm resistance (for 4 mm screws)CharacteristicsResistance Tolerance: ±0.1 %TCR (ppm/°C): ±25 ppm/ºCRated Power: 0.3 WAllowable maximum current: 35 mARecommended input current: 4-20 mARated Ambient Temperature: 70 ºCOperational Temperature Range: -25 to +80 ºCStorage Temperature Range: -40 to +85 ºC
