1SAZ511201R1001 | ABB TA450DU185 130-185A Thermal Overload Relay

Part Number: 1SAZ511201R1001SpecificationsDescription: TA450DU-185 Thermal Overload RelayProduct ID: 1SAZ511201R1001Extended Product Type: TA450DU-185Product Net Weight: 1.5 kgProduct Net Width: 193 mmProduct Net Height: 75 mmProduct Net Depth: 172.5 mmDegree of Protection: IP20Ambient Air Temperature: Operation -25 ... +55 C Operation Compensated -25 ... +55 C Storage -40 ... +70 CStandards: IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 UL 60947-1 UL 60947-4-1Rated Impulse Withstand Voltage (Uimp): Auxiliary Circuit 6 kV Main Circuit 6 kVRated Insulation Voltage (Ui): 690 VNumber of Poles: bRated Frequency (f): Auxiliary Circuit 50 Hz Auxiliary Circuit 60 Hz Auxiliary Circuit DC Main Circuit 50 Hz Main Circuit 60 HzPower Loss: at Rated Operating Conditions per Pole 2.2 WSuitable For: A210 A260 A300 AF210 AF260 AF300eClass: 7.0 27371501Mounting Position: Position 1 to 4Number of Auxiliary Contacts NO: 1Number of Auxiliary Contacts NC: 1Connecting Capacity Main Circuit: Bar < 21.0 x 28.4 mmGOST Certificate: 1SAA941000-2704Maximum Operating Voltage UL/CSA: Main Circuit 600 V ACMaximum Operating Altitude Permissible: 2000 mTightening Torque UL/CSA: Auxiliary Circuit 12 in·lbConnecting Capacity Auxiliary Circuit: Flexible with Ferrule 1/2x 0.75 ... 2.5 mm Flexible 1/2x 0.75 ... 2.5 mm Rigid 1/2x 0.75 ... 4 mmGL Certificate: 1SAA941000-0403 1SAA941006-0403Ampere Rating UL/CSA: 185 ANumber of Protected Poles: 3EAN: 4013614286070Minimum Order Quantity: 1 pieceCustoms Tariff Number: 85364900Package Level 1 Width: 215 mmPackage Level 1 Height: 140 mmPackage Level 1 Length: 200 mmPackage Level 1 Gross Weight: 1.75 kgPackage Level 1 Units: 1 pieceRated Operational Voltage: Auxiliary Circuit 440 V DC Auxiliary Circuit 500 V AC Main Circuit 1000 V ACRated Operational Current (Ie): 185 ARated Operational Current AC-3 (Ie): 185 AConventional Free-air Thermal Current (Ith): Auxiliary Circuit NC 10 A Auxiliary Circuit NO 6 ARated Operational Current AC-15 (Ie): (120 V) NC 3 A (120 V) NO 1.5 A (240 V) NC 3 A (240 V) NO 1.5 A (400 V) NC 1.9 A (400 V) NO 1 A (440 V) NC 1 A (440 V) NO 1 A (500 V) NC 1 A (500 V) NO 1 ARated Operational Current DC-13 (Ie): (125 V) NC 0.25 A (125 V) NO 0.25 A (24 V) NC 1.25 A (24 V) NO 1.25 A (250 V) NC 0.12 A (250 V) NO 0.04 A (60 V) NC 0.25 A (60 V) NO 0.25 APollution Degree: 3Recommended Screw Driver: Main Circuit Pozidriv 2Setting Range: 130 ... 185 AAmbient Air Temperature Compensation: YesResistance to Shock acc. to IEC 60068-2-27: 11 ms Pulse 12gRoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendmentContact Rating UL/CSA: (NC:) B600 (NO:) C300Connecting Capacity Auxiliary Circuit UL/CSA: Flexible 1/2x 18-14 AWG Stranded 1/2x 18-14 AWGData Sheet, Technical Information (Part 2): 1SAZ500501F0001Instructions and Manuals: GJZ5207002P0002ABS Certificate: 1SAA941000-0102BV Certificate: 1SAA941000-0201CB Certificate: 1SAA941006-2002CCC Certificate: 1SAA941004-3803cUL Certificate: cUL_E48139Data Sheet, Technical Information: 1SBC100173C0201Declaration of Conformity - CE: 1SAD938512-0043DNV Certificate: 1SAA941000-0303EAC Certificate: 1SAA941002-2701LR Certificate: 1SAA941000-0504RMRS Certificate: 1SAA941000-0703RoHS Information: 1SAA941003-4404UL Certificate: UL_E48139 1SAA938001-1604E-nummer: 3228715ETIM 4: EC000106 - Thermal overload relayETIM 5: EC000106 - Thermal overload relayETIM 6: EC000106 - Thermal overload relayUNSPSC: 39121521Object Classification Code: F
