1794-IB16D | Allen Bradley FLEX Digital DC Input Module

Part Number : 1794-IB16DModel1794-IB16DNumber of outputs16, current, sinkingRecommended terminal base unit 1794-TB32, 1794-TB32S, 1794-TB62DS, 1794-TB62EXD4X15On-state voltage, min10V DCOn-state voltage, nom24V DC On-state voltage, max31.2V DC On-state current, min2.0 mAOn-state current, max1.5 mAOff-state voltage, max5.0V DCOff-state current, max1.5 mANominal input impedance3.1 k Isolation voltage50V (continuous), Basic Insulation TypeType tested @ 2121V DC for 2 s, between field side and systemNo isolation between individual channelsOutput signal delay? Off to On On to OffRefer to Input Filter Time tableFlexBus current30 mA @ 5V DCPower dissipation, max8.5 W @ 31.2V DCThermal dissipation, max29 BTU/hr @ 31.2V DCSensor power, voltage drop, max2.2V DCSensor power, current, maxSensor power, current, maxSensor power line, short detect circuit, min1.0 A (in 10 s)Sensor power line, open wire detect, max50 ?ADetect reverse polarity voltageMinimum 10V: Module must detect if the reverse polarityexternal power supply voltage is greater than the value.(1) Input off-to-on filter time is the time from a valid input signal to recognition by the module. Input on-to-off filter time is time from the input signal dropping below the valid level to recognition by the module.
