1762-OF4 | Allen Bradley 1762 MicroLogix Analog Output Module

SpecificationsModel: 1762-OF4Dimensions, H x W x D: 90 x 40 x 87 mm (3.54 x1.58 x 3.43 in.)Approximate Shipping Weight (with carton): 235 g (8.28 oz)Bus current draw, max: 40 mA @ 5V DC; 165 mA @ 24V DCAnalog normal operating range: Voltage: 0 10V DC; Current: 4 20 mAFull scale? analog ranges: Voltage: 0 10.5V DC; Current: 0 21 mAResolution: 12 bits (unipolar)Repeatability?: ?0.12%Output group to system isolation: 30V AC/30V DC rated working voltage4 (IEC Class 2 reinforced insulation) type test: 500V AC or 707V DC for 1 minuteModule power LED: On: indicates power is applied.Recommended cable: Belden 8761 (shielded)Heat Dissipation: 2.8 WWiring category?: 2 - on signal portsPilot duty rating: Not ratedEnclosure type rating: IP20North American temp code: T3CVendor ID code: 1Product type code: 10Product code: 66NOTE:The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues to convert the analog output up to the maximum full scale range.Repeatability is the ability of the output module to reproduce output reading when the same controller value is applied to it consecutively, under the same conditions and in the same direction.Use this Conductor Category information for planning conductor routing.Rated working voltage is the maximum continuous voltage that can be applied at the terminals with respect to earth ground.
