1756-L83E/B | Allen Bradley ControlLogix Standard 5580 Processor (Series B)

Technical SpecificationsUser Memory: 10 MBDigital I/O, max: 128,000Analog I/O, max: 4000Total I/O, max: 128,000Optional nonvolatile memory storage: 2 GB Secure Digital Card (1784-SD2), ships pre-installed in the controller²Energy storage module: Embedded in controller, nonremovableCurrent draw @ 1.2V DC: 5.0 mACurrent draw @ 5.1V DC: 1.20 APower dissipation: 6.2 WThermal dissipation: 21.2 BTU/hrIsolation voltage: 50V (continuous), Basic Insulation type, USB port to backplane, Ethernet port to backplane, and USB port to Ethernet portType tested at 1000V AC for 60 secondsSlot width: 1Module location: Chassis-based, any slotWire size: Ethernet connections:Ethernet cabling and installation according to IEC 61918 and IEC 61784-5-2North American temperature code: T4ATEX temperature code: T4IECEx temperature code: T4Enclosure type rating: None (open-style)
