1756-L63 | Allen Bradley ControlLogix 5560 Controller

Part Number: 1756-L63Model: ControlLogix 5560 ControllerManufacturer: Allen BradleyTechnical SpecificationsModel: 1756-L63User memory: 8 MBI/O memory: 478 KBOptional nonvolatile memory storage: 128 MB (1784-CF128)Digital I/O, max: 128,000Analog I/O, max: 4000Total I/O, max: 128,000Current draw @ 5.1V DC: 1200 mACurrent draw @ 24V DC: 14 mAPower dissipation: 3.5 WThermal dissipation: 11.9 BTU/hrIsolation voltage: 30V (continuous), basic insulation type, RS-232 to system; Type tested at 720V DC for 60 sSerial cables: 1756-CP3 or 1747-CP3, right angle connector to controller, straight to serial port, 3 m (9.84 ft)Weight, approx: Series A: 0.32 kg, (0.71 lb); Series B: 0.35 kg, (0.78 lb)Slot width: 1Module location: Chassis-based, any slotWire category¹: 2 - on RS-232 portEnclosure type rating: None (open-style)NOTE:Use this conductor category information for planning conductor routing as described in the system level installation manual.
