160P12CC6B | ITT Neo-Dyn Pressure Switch

Ordering Information Model 160P Neo-Dyn® Series 160P Differential Pressure Switch Wetted Material 1 Aluminum port and body, Teflon coated polyimide diaphragm, Buna-N O-Rings and stainless steel Adjustable Range 2 .75 psid dec. to 15 psid inc. (0.1 bar dec. to 1.0 bar inc.) Electrical Form CC 11 amp, 1/4 hp at 125 or 250 VAC; 5 amp resistive, 3 amp inductive at 28 VDC; .5 amp resistive at 125 VDC Enclosure 6 Includes an explosion proof, hermetically-sealed electrical assembly. EX d IIC.Division 1 and 2, Class I, Groups A, B, C, and D; Class II, Groups E, F, and G.NEMA 4X, 7, and 9; IP66. Leads are factory sealed and Pressure Switches are Dual Seal Certified. Miscellaneous B Viton O-Ring
