110P14CC6AW | ITT Neo-Dyn® Series 110P Pressure Switch

Ordering Information Model 110P Series 110P Pressure Switch Wetted Material 1 Aluminum port, Teflon coated polyimide diaphragm and Buna-N O-Ring Adjustable Range 4 2.75 psig dec. to 15 psig inc. (0.2 bar dec. to 1.0 bar inc.) Electrical Form CC 11 amp, 1/4 hp at 125 or 250 VAC; 5 amp resistive, 3 amp inductive 28 VDC;.5 amp resistive at 125 VDC Enclosure 6 Includes an explosion proof, hermetically-sealed electrical assembly. EX d IIC.Division 1 and 2, Class I, Groups A, B, C, and D; Class II, Groups E, F, and G.NEMA 4X, 7, and 9; IP66. Leads are factory sealed and Pressure Switches are Dual Seal Certified. Miscellaneous AW Expoxy paint exterior - extra protection for severe environmentsStainless steel screws - exterior (standard with wetted material 4)
