110P12C6BMN | ITT Neo-Dyn® Series 110P Pressure Switch

Ordering Information Model 110P Series 110P Pressure Switch Wetted Material 1 Aluminum port, Teflon coated polyimide diaphragm and Buna-N O-Ring Adjustable Range 2 7" H20 dec. to 100" H20 inc. (17 millibar dec. to 249 millibar inc.) Electrical Form C 15 amp at 125 or 250 VAC; 1/8 hp at 125 VAC; 1/4 hp at 250 VAC; .5 amp resistive, .04 amp inductive at 125 VDC Enclosure 6 Includes an explosion proof, hermetically-sealed electrical assembly. EX d IIC.Division 1 and 2, Class I, Groups A, B, C, and D; Class II, Groups E, F, and G.NEMA 4X, 7, and 9; IP66. Leads are factory sealed and Pressure Switches are Dual Seal Certified. Miscellaneous BMN Viton O-RingGold electrical contacts for extremely low current applications(1 Amp at 125 VAC; 1 Amp Res, 0.5 Amp Ind. at 28 VDC)ATEX and IECEx with CE Mark
